Board Pickup
Freshly produced corrugated board is collected from the single facer through the take-up device.
Conveyor Type
Overhead Bridge
Working Width
1200–2500 mm
Structure
Heavy Duty Steel
Drive System
AC Frequency Drive
Safety
Guard & Walkway
Application
2-Ply Board Transfer
The OH-201 Overhead Bridge Conveyor System provides safe and efficient transportation of paper reels within corrugated board production plants. Its automated pick-up mechanism, robust bridge construction, and variable-speed drive improve workflow, reduce handling time, and support uninterrupted production.
Delivering Quality Machines Across the Globe
USA
UAE
Saudi Arabia
Australia
France
Canada
South Africa
Brazil
India
Mexico
| Parameter | Specification |
|---|---|
| Model | OH-201 |
| Machine Type | Overhead Bridge Conveyor System |
| Conveyor Design | Overhead Bridge Type |
| Structure | Heavy-Duty Fabricated Steel |
| Material Handling | Automatic Paper Reel Transfer |
| Pick-Up System | Automatic Pick-Up Device |
| Speed Controlt | AC Frequency Drive (VFD) |
| Safety Features | Life Guard, Chequered Bridge & Stair Access |
The OH-201 Overhead Bridge Conveyor System is widely used in corrugated board manufacturing plants for safe and efficient paper reel transportation.
Four-step conveying process for smooth sheet transfer, synchronized movement, and continuous corrugated board production.
Freshly produced corrugated board is collected from the single facer through the take-up device.
The overhead bridge conveyor transports the board smoothly while maintaining proper web tension.
AC frequency drive and geared motors synchronize the board movement for continuous production.
Corrugated board is delivered safely to the next production section without interruption or damage.
The OH-201 is an automated overhead conveyor designed to transport paper reels safely and efficiently within corrugated board production lines.
Its primary function is to automatically pick up, transport, and position paper reels, reducing manual handling and improving production efficiency.
The system uses an individual geared motor with an AC Frequency Drive (VFD) for smooth and adjustable conveyor movement.
The OH-201 includes a life guard system, chequered bridge platform, and three stair access to ensure operator safety during operation and maintenance.
The conveyor system is available in working widths ranging from 1200 mm to 2500 mm.
The OH-201 is ideal for corrugated box manufacturers, paper mills, packaging industries, and automated corrugated board production plants.
